PL-DR02BT is a two-channel output control, based on IEEEE802.3BT standard PoE power supply intelligent LED driver.
Product Information :
PL-DR02BTProduct Introduction
The intelligent PoE LED driver is suitable for indoor LED lighting, and is connected to the Internet and powered by a Category 5 network cable and a PoE switch that complies with IEEE802.3BT standard. The two outputs of PL-DR02BT can supply power for two LED lamps. The power of a single lamp does not exceed 60W, and the total power generally does not exceed 90W. Each lamp can be controlled individually through settings or system configuration.
The smart PoE LED driver is a constant current power supply with a power supply range of 52V-57V. It is recommended to choose a suitable lamp, and the power supply efficiency of the driver is better.
The input and output of PL-DR02BT power supply do not exceed the safe voltage range of 57VDC, which is convenient for installation and construction. The integrated design of two power supplies and one sensor reduces construction costs. Products are widely used in office and architectural lighting fields.
Connection Scheme
LED Driver technical parameter table | |||
Model | PL-DR02BT | Data Speed | 10/100Mbps |
Input | 44-57V dc 1.7A | ||
Protocol | IEEE802.3 bt Class 8 | ||
Power Pins | 4、5 ( + ) 7、8 ( - ) & 3、6 ( + ) 1、2 ( - ) | ||
Output voltage | 5-55V dc | Output current | 650mA single channel |
Output port | 5.5*2.5mm female plug *2+ RS485 *1 | ||
Communication | MQTT | ||
Frequency | 20KHz | ||
Duty cycle | 10%-100% | ||
Dimming | Microwave / brightness / manual | ||
Management | Remote management available | ||
Safety | Overvoltage/overcurrent protection | ||
Color temp | Natural light / cool white / warm white | Brightness range | Monochrome(1000-8191) |
Lamp | Energy-saving lamps / light strips / light bars / ceiling lamps / pendant lamps / floor lamps, etc. | ||
Operating temp | -20℃ to 60℃ | Operating humidity | 20% to 80%, non-condensing |
Storage temp | -40℃ to 150℃ | Storage humidity | 10% to 90%, non-condensing |
Material | Metal | Color | Silver |
Indicator light | Green:PoE Yellow:Data | ||
Mounting | Wall-mounted | IP Rated | IP40 |
Installation Matters
1.Connecting a PoE Switch PoE In input port Connects to a PoE switch that complies with the IEEE 802.3BT standard through a Cat5e network cable. |
2.Connected LED light LED1 and LED2 output ports connect LED lights that meet voltage and current requirements and support various types of lights.lamps, etc. |
|
|
Diagram of connecting switch |
Schematic diagram of connecting LED lights |
3.Dual circuit control lights It can independently control the switching state and brightness of two LED lights. |
4.Single channel control light By setting, two outputs can be connected to one LED light, realizing unified switch and brightness adjustment. |
|
|
Diagram of dual circuit control lights |
Schematic diagram of single channel control light |
